The EcoChill System offers an efficient and environmentally friendly solution for transporting frozen foods. By using electricity instead of traditional engines, this system significantly extends the vehicle's lifespan. Key components include a compressor, condenser, control box, and eutectic freezing plates. The system maintains low temperatures for extended periods by freezing the liquid at night and releasing latent heat during the day.
Operates on 380V (220V) electricity, independent of the vehicle engine, enhancing performance.
Capable of operating at -40°C, maintaining a constant -25°C for up to 16 hours.
Noise-free and vibration-free, providing a superior transportation environment.
Reduced mechanical failures as the system is independent of the vehicle engine.
| Load | Body Size (LxWxH mm) | Compressor | Electricity | Plates | Cooling Cap. | Refrigerant |
|---|---|---|---|---|---|---|
| 1.0t | 3160x1740x1650 | 3 HP | 380V | 5 | 9450 kcal | R404A |
| 2.5t | 4380x2000x1920 | 5 HP | 380V | 8 | 15120 kcal | R404A |
| 3.5t | 4800x2000x2000 | 5 HP | 380V | 9 | 17010 kcal | R404A |
| 5.0t | 6250x2450x2300 | 5 HP | 380V | 11 | 20790 kcal | R404A |
| 8.0t | 7500x2500x2300 | 5 HP | 380V | 13 | 24570 kcal | R404A |
| 11.0t | 9150x2500x2250 | 7.5 HP | 380V | 15 | 28350 kcal | R404A |
